Technical table
| Cod. | Modello | D mm | H mm | L mm | L1 mm | C mm | B mm | A mm | d mm | E mm | F mm | MGR mm | n | Peso gr | 3D |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7117001 | VPR/100-MR | 100 | 35 | 102 | 54 | 14 | 16 | 24 | Ø4 | 11 | 30 | 21x50 | M5 | 251 | 3D |
| 7117005 | VPR/125-MR | 125 | 44 | 116 | 64 | 16 | 18 | 32 | Ø6 | 13 | 36 | 23x55 | M5 | 419 | 3D |
| 7117010 | VPR/150-MR | 150 | 48 | 130 | 69 | 18 | 20 | 32 | Ø6 | 13 | 38 | 25x65 | M6 | 539 | 3D |
| 7117015 | VPR/200-MR | 200 | 58 | 163 | 82 | 21 | 24 | 40 | Ø6 | 16 | 45 | 28x85 | M6 | 992 | 3D |
| 7117020 | VPR/250-MR | 250 | 66 | 171 | 90 | 22 | 30 | 48 | Ø8 | 17 | 50 | 28x85 | M6 | 1612 | 3D |
| 7117025 | VPR/300-MR | 300 | 76 | 181 | 100 | 24 | 35 | 58 | Ø8 | 18 | 57 | 28x85 | M6 | 2723 | 3D |
NOTE:
Special inch and metric bores, keyways, set screw holes, ect. available upon request.
Request a quote
Select the model, add it to the list of products to be quoted and send the request to receive a personalized quotation as soon as possible.
Product specifications
The VPR/MR features a snap-action foldable rotating knob that saves space and improves maneuverability. Made from galvanized steel, the product is resistant and designed to offer high performance in industrial environments.
Protruding galvanised steel hub. Flip-top rotary knob.
The VPR/MR hub, with its snap-action foldable rotating knob, is designed to optimize space and improve functionality in industrial applications.
Here are some examples of application fields for the VPR/MR hub:
Industrial machinery
Agricultural machinery
Hydraulics
